Graco Ultra Max II Electric Airless Sprayer
The Graco Ultra Max II Electric Airless Sprayer is equipped with a enabling it to efficiently accommodate multiple guns. Additionally, it incorporates the well-established Chromex pump, renowned for its extended lifespan of twice the industry standard. Furthermore, this sprayer features the Contractor PC gun, which is not only lightweight but also user-friendly, ensuring a hassle-free experience.
Categories: Contractor Equipment, Electric Sprayers, Graco
- DOCUMENTS & BROCHURES
- MODELS
300712ENEU Ultra Max II Standard
300713ENEU ULTRA MAX II
300714ENEU Ultra Max II 1095 IronMan
332916F, 69579510951595MarkIVMark VMark VIIMark X Electric Airless Sprayers Operation, English
333281F, 695 795 1095 Mark IV Mark V Mark VII Mark X Electric Airless Sprayers, Parts, English
Model Name: | ULTRA MAX II STANDARD 695 | ULTRA MAX II STANDARD 795 | ULTRA MAX II STANDARD 1095 | ULTRA MAX II PROCONTRACTOR 695 | ULTRA MAX II PROCONTRACTOR 795 | ULTRA MAX II PROCONTRACTOR 1095 | ULTRA MAX II IRONMAN 1095 |
Part Numbers: EU – 230V | 17E632 | 17E639 | 17E646 | 17E635 | 17E642 | 17E647 | 17E650 |
Part Numbers: IT, DK, CH – 230V | 17E633 | 17E640 | – | 17E636 | 17E643 | 17E648 | – |
Part Numbers: UK – 110V | 17E634 | 17E641 | – | 17E637 | 17E644 | – | – |
Max. Tip Size: 1 gun | 0.031” | 0.033” | 0.035″ | 0.031” | 0.033” | 0.035″ | 0.035″ |
Max. Tip Size: 2 guns | 0.023″ | 0.025″ | 0.027″ | 0.023″ | 0.025″ | 0.027″ | 0.027″ |
Max. Flow – l/min (gpm) | 3.6 (0.95) | 4.1 (1.1) | 4.5 (1.2) | 3.6 (0.95) | 4.1 (1.1) | 4.5 (1.2) | 4.5 (1.2) |
Max. Pressure – bar (PSI) | 227 (3300) | 227 (3300) | 227 (3300) | 227 (3300) | 227 (3300) | 227 (3300) | 227 (3300) |
Motor rating – kW (HP) | 1.3 (1.75) | 1.5 (2.0) | 1.65 (2.2) | 1.3 (1.75) | 1.5 (2.0) | 1.65 (2.2) | 1.65 (2.2) |
Temperature setting | – | 43 (94) | 43 (94) | 43 (94) | 43 (94) | 43 (94) | 43 (94) |
Weight – kg (lbs) | 43 (94) | 45 (98) | 55 (120) | 50 (111) | 52 (115) | 64 (141) | 56 (121) |
FEATURES | |||||||
BlueLink | X | X | X | X | X | X | X |
SmartControl with ProGuard | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 |
LED display | X | X | X | X | |||
Hydraulic Pressure Gauge | X | X | X | X | |||
FastFlush | X | X | X | X | X | X | X |
WatchDog | X | X | X | X | X | X | X |
Endurance Pump | X | X | X | Endurance Vortex | Endurance Vortex | Endurance Vortex | Endurance Vortex |
ProConnect | X | X | X | X | |||
Piston Rod | Chromex | Chromex | Chromex | MaxLife | MaxLife | MaxLife | MaxLife Extreme |
Sleeve | Hard Chrome | Hard Chrome | Hard Chrome | MaxLife | MaxLife | MaxLife | MaxLife |
Rock Catcher | Standard | Standard | Standard | CrushProof | CrushProof | CrushProof | CrushProof |
TiltBack | X | X | X | X | X | X | X |
QuickReel | X | X | X | ||||
Flat-Proof Tires | X |
